Sold-220-Ton x 161″ Bystronic Xpert 250/4100 Press Brake
Bystronic CNC control, Hydraulic Clamping, and (2) Dynamic Sheet Supports
New in 2014
Request Quote
The Bystronic Xpert series
All Xperts feature high acceleration of the upper beam and backgauge, fast set up and low power consumption. Along with Bystronic’s user friendly control and ease of use through ergonomic design. Plus, the Xpert series features the unique active crowning feature with multiple cylinders, the only system like it in the industry.
Machine Specifications:
Downstroking
Maximum Tonnage: 220
Length: 161″
Between Housing: 147″
Stroke Length: 12.4
Open Heights: 21.6”
Throat Depth: 16”
Capable
Tonnage: 220
Bending Length: 161”
Standard Stroke: 12.5”
Open Height (D): 21.7”
Distance between side frames: 147”
Throat (T): 15.8”
Table Width: 2.4”
Back Gauge Specs:
X-Axis (2/4/5 axis) – 41,4” X Axis Travel (2/4/5 axis) – 23,7” X-Axis Speed (2/4/5 axis) – 1536 in/min X-Axis Position accuracy (2/4/5 axis) 0.0008”
R-Axis Travel (2/4/5 axis) – 9,9”
R-Axis Speed (2/4/5 – axis) – 473 in/min R-Axis Position Accuracy (2/4/5 – axis) – 0.004” Z-Axis Travel: 116”
Z-Axis Speed (4/5 – axis): 3544 in/min Z-Axis Speed for 6-axis (up to) – 3550 in./min.
Z-Axis Position Accuracy 4/5-axis): 0.004”
Max Y Approach Speed: 472 in/min
Y-Approach in High Speed (up to)*: 520 in/min.
Max. Y-Working Speed: 23.6 in/min.
Y-Working Speed in High Speed (up to): 47.2 in/min* Y-Working Speed in High Speed for Robot Operation (up to)*: 47.2 in/min.*
Y-Position Accuracy: 0,00016”
Oil Capacity: 159 gal
Electric Supply: 29.5 HP
Weight: 36000 lbs
Length, approx. (L): 194.9”
Width, approx. (W): 74.8”
Height, approx. (H): 113.2”
