SOLD-88 Ton Amada HD 8025 NT Press Brake
Manufactured in 2013
Machine Number 1174
Request Quote
Amada HD NT Series
The Amada HD NT Series is an ultra-high precision, down-acting system featuring advanced hydraulics that provide the ultimate in positioning accuracy. The Amada HD press brakes are servo-hydraulic hybrid press brakes like the HDS and HG models. One main difference in the HD series is the crowning system. The HD series uses a wedge style crowning.
System Specifications
Tonnage Capacity: 88 Tons US
Maximum Bending Length: 101.2”
Distance Between the Frames: 83.5”
Throat Depth: 16.5”
Stroke Length: 7.87”
Open Height: 18.5”
Open Height w/ Holders: 11.75”
Oil Capacity: 9 gallons
Speed
Approach Speed: 4.72 inches per second
Bending Speed: 0.39 inches per second
Return Speed: 4.72 inches per second
Dimensions
Overall Length: 162.2”
Overall Width: 98.8”
Overall Height: 105.1”
Ground Height: 105.9”
Machine Weight: 12, 346lbs.
Backgauge and Control
Backgauge Range: 27.5”
Backgauge Vertical Range: 9.84”
Control Type: Amada AMNC-PC
Axis Under CNC Control: 7
RAM: D1 & D2
Backgauge: L1 & L2
Backgauge Horizontal: Y1 & Y2
Backgauge Vertical: Z
Ram Repeatability: ±0.00004”
