SOLD- 60 Ton x 1.3 Meter Amada EG-6013-M10 Fully Electric Press Brake
Manufactured in 2019
Request Quote
Fully Electric Servo Press Brake
The Amada EG-6013 is a 60 ton x 1.3 meter fully electric servo press brake. It features the Dual Servo Power (DSP) Drive for extremely fast approach, bending and return speeds and providing faster cycle times. This results in more parts per hour and more productivity. Also, it is equipped with Amada’s latest 3i AMNC control with 7-Axis of control and a 5-axis backgauge.
Specifications:
Capacity: 60 Tons
Table Length: 55.1”
Max. Bending Length: 55.1”
Distance Between the Uprights: 39.8”
Throat Depth: 9.1”
Length of Stroke: 5.9”
Open Height: 16.5”
Overall Length: 97.2”
Overall Width: 78.0”
Overall Height: 104.7”
Net Weight: 8157 lbs.
Environmental Temperature: 32 degrees ~ 104 degrees F
Equipped with:
Fully Electric Servo Drive System
Amada 3i Control
5-Axis Backgauge
