SOLD-Trumpf TruBend Cell 5000
With 187 Ton Trumpf TruBend 5170S Press Brake and BendMaster 150 Robot
Manufactured in 2014
Machine Number 1292
Request Quote
Trumpf TruBend Cell 5000
Easy programming, fast automated bending: The TruBend Cell 5000 is the perfect solution for all those who value productive and flexible automation, for the widest possible range of parts. TruBend Cell 5000 enables you to process parts cost-efficiently and achieve high productivity. The BendMaster relieves the operator
of many onerous tasks, especially when processing large and heavy workpieces weighing up to 220 lbs. The bulk of the work is handled by the machine – working around the clock, seven days a week, if necessary. You can always rely on our automated bending solutions to produce parts of consistently high quality.
Technical Data for TruBend 5170S
Model: TruBend 5170S Hydraulic Press Brake
Press Force: 187 Tons
Bending Length: 167″
Width: between Columns: 145″
Usable Installation Height: 24”
Throat: 16.5″
Operating Height: 43.1-43.8″
Inclination of Beam: ± 0.39″
Speeds
Y Rapid: 520 ipm
Y Working: 24-36 ipm
Y Return Traverse: 520 ipm
X Axis: 2362 ipm
R Axis: 780 ipm
Z Axis: 2362 ipm
Precision
Y Axis Position Accuracy: 0.0002″
X Axis Position Accuracy: 0.002″
R Axis Position Accuracy: 0.003″
Working Range
Stroke: 17.52”
Travel Path X Axis: 24”
Max. Gauge Area in X: 34”
Travel Path R Axis: 10”
Connection Values
Connected Load: 32 kVA
Oil Capacity: 58 gal
Technical Data for BendMaster 150
Model: BendMaster 150
Maximum Part Size: 118” x 59”
Profiles: Up to157”
Maximum Part Weight: 331 lbs
Maximum Carrying Capacity: 331 lbs
Minimum Sheet Thickness: 0.7 mm
Part Length: 26.24’ – 52.49’
Maximum Sheet Stack: 27.56”
Maximum Stack Height for Finished Parts: 47.24”
Dimensions
BendMaster Weight: 2344 kg (5168 lb)
TruBend 5170 Dimensions: 167” x 73” x 118”
TruBend 5170 Weight: 35280 lbs
Equipped with
Stopa Prep, Cart and Door
