SOLD-33 Ton Amada Vipros 367 Queen Turret Punch Press
Equipped with 58 Station 2 Auto-Index Turret and Fanuc 18P Control
Manufactured in 1999
Request Quote
Amada Turret Punch Press
The Amada Vipros 367 Queen is a high speed hydraulic turret punch press. The Amada Vipros Queen series turret punches is well regarded for its reliability and versatility processing materials up to 1/4″ thick. This Amada Vipros 367 Queen turret punch’s large table is capable of handling 5′ x 12′ sheet with one repositioning cycle. The Fanuc 18P control allows the user greater ram control for running forming tools like the Wilson Wheel.
Specifications – Motion Package
Travel Method: X and Y axes work piece movement
Control Method: X, Y, T & C
Drive Motors: Fanuc AC Servo (X, Y, T, C)
Maximum Sheet Size: 60″ (Y) x 144″ (X) with one repositioning cycle.
Additional support tables are required for material lengths greater than 72”
Maximum Sheet Thickness:
Ball Transfer Table 0.250″
Brush Table 0.15″
Maximum Material Weight:
Ball Transfer Table 220 lb.
Brush Table 110 lb.
Maximum Axis Travel: 72.0″ (X) by 60″ (Y)
Max. Table Speed: ( X / Y / Combined ) 2559 IPM / 1968 IPM / 3228 IMP
Punching Accuracy: ±0.004″
Positioning Accuracy: ±0.001″
Repeatability: ±0.001″
Specifications – Punching System
Press Capacity: 33 Tons
Press Stroke: 1.575″
Stroke Rate (X/Y):
Pitch Stroke Rate
0.079″ 0.118″ 520/420
0.079” 0.236” 360/360
0.315” 0.315” 275/275
1.000″ 0.315″ 275/240
Maximum Hole Diameter: 4.500″
Tool Type: Amada Thick Turret
Turret Rotation Speed: 30 RPM
Feed Clearance: 0.787″
Specifications – Turret
58 Station 2 Auto Index Thick Style
Specifications – Fanuc 18PC Controller
Model: Fanuc 18PC (with PHNC)
Control Function: X, Y, T & C
Input Method: MDI, 3½” Floppy, DNC
Minimum Command Unit: 0.001″ (X, Y) .010 (C)
Minimum Travel Unit: 0.001″ (X, Y) .010 (C)
Operating Modes Automatic, MDI & Manual
Display Modes Program Contents, Position Information, Program Check, Parameters, Tool Hit Counter, Self Diagnostics Interlock Displays Oil Temperature, Oil Pressure, Door Open
