SOLD-3500-Watt Amada LCG-3015 CO2 Laser Cutting System
Manufactured in 2015
Turbo Blower replaced in 2025
Request Quote
Amada CO2 Flying-Optics Style Laser
The Amada LCG-3015 is a flying-optics style CO2 laser built on a helical rack and pinion drive system for both the X & Y Axes. The helical rack and pinion drive system is capable of faster acceleration and rapid transverse speeds than traditional rack and pinion systems, without the extra cost and maintenance of a linear drive system. The LCG CO2 series is equipped with an Amada/Fanuc 3500i-C resonator, designed specifically for this system to achieve similar cut quality as more powerful CO2 systems.
Technical Data
Travel method: Material remains stationary, X, Y and Z-axis movement
Drive method: X and Y-axis helical rack and pinion, Z-axis ball screw
Axis travel: 121″ x 61″ x 3.93″ (cutting head)
Maximum thickness: 3/4″ Mild steel, 3/8″ stainless steel, 5/16″ aluminum
Maximum work weight: 2000 lbs.
Rapid traverse:
X, Y = 4,724 inches per minute
Simultaneous= 6,693″ inches per minute
Z=4,724 inches per minute
Repeatability: 0.0002″
Z-Axis: High speed capacitive sensing
CNC: AMNC-PC-OS, Windows embedded
Assist gas control: Automatic select
Resonator: AF3500i-C
Machine weight: 28,000 lbs. (including shuttle table)
Power requirements: 200/220V 10% 50/60Hz
Equipped With
Chiller
Dust Collector
Yellow Frame with Crane and Vacuum Lift
New Turbo Blower in 2025
