60 Ton x 4′ Cincinnati AutoForm+ Press Brake
Manufactured in 2005
Machine Number 1237
Request Quote
Auto Form Press Series Press Brake
The Cincinnati Auto Form (AF) press brake series was Cincinnati’s top of the line model and a version is still in production today. As with other Cincinnati models, this series features the rugged reliability that Cincinnati is known, but with faster speeds and better accuracy than the CB/PF series machines. This machine has a 4′ and a 60 Ton press capacity.
Machine Specifications
Model: 60AF+
Max Tonnage: 60 Tons
Overall Length: 4′
Closed Height: 9”
Standard Stroke: 8”
Open Height: 17”
Throat Clearance: 10”
Overall Height: 104”
Ram Speeds:
Approach: 270 ipm
Forming: 1 to 120 ipm
Return: 1 to 290 ipm
Ram Repeat: 0.0004”
Equipped With
CNC Control
CNC 2-Axis Backgauge
