Haas VF-3SSYT Vertical Machining Center
Manufactured in 2018
Machine Number 1218
Request Quote
Haas VF Vertical Machining Centers
Every VF Series vertical machining center provides outstanding features at an excellent price, and features a wide range of available options to customize your machine to your exact needs. The VF-3 through VF-5 models feature larger work envelopes than the smaller VF-1 and VF-2 models.
Travels
X-Axis: 40”
Y-Axis: 26”
Z Axis: 25”
Spindle Nose to Table (~max): 29.2”
Spindle Nose to Table (~min): 4.2”
Spindle
Max. Rating: 30 HP
Max. Speed: 12,000 RPM
Max Torque: 90.0 ft-lbf@ 2000 rpm
Spindle Taper: CT40
Table
Length: 54”
Width: 24”
T-slot Width: 0.626” to 0.630”
T-slot Center Distance: 3.15”
Number of Std T-Slots: 7
Max. Weight on Table (evenly distributed): 1750 lbs.
Feedrates
Max. Cutting: 833 ipm
Rapids on X: 1400 ipm
Rapids on Y: 1400 ipm
Rapids on Z: 1400 ipm
Axis Motors
Max. Thrust X: 3085 lbf
Max. Thrust Y: 3085 lbf
Max. Thrust Z: 3923 lbf
Tool Changer
Type: SMTC
Capacity: 30+1
Max. Tool Diameter (full): 2.5”
Max. Tool Diameter (adjacent empty): 5.0”
Max. Tool Length (from gage line): 13”
Max. Tool Weight: 12 lb
Tool-to-Tool (avg): 1.80 s
Chip-to-Chip (avg.): 2.40 s
General
Coolant Capacity: 55 gal
Machine Weight: 15000 lbs
