6000-Watt Alpha Lazer Fiber M 4020 Laser Cutting System
Equipped with Siemens Sinumerik Control
Manufactured in 2021-Never Installed-Still in Original Packaging!
Machine Number 1200
Request Quote
Alpha Lazer M Series Fiber
Alpha Lazer specializes in laser cutting equipment for the metal industry, including workshops, metal cutting plants, and equipment manufacturers. Alpha Lazer’s CNC laser cutting machines are equipped with state-of-the-art features, including the world’s leading laser cutting head, a user-friendly Siemens CNC controller, and a powerful IPG fiber laser source. The Fiber M 4020 has a 6′ x 12′ working range and this machine has 6000-Watt IPG laser source. This machine has never been used and is still in its original packaging.
Machine Specifications
Working Range: 6’ x 12’
Lateral Door
Self-Lubricating
Max Sheet Size: 160” x 80”
Max Sheet Weight: 52 lbs./sq.in.
Remote Access
Controller Unit
Siemens Sinumerik 84 D SL
18.5” Touch Panel
Remote Access
Laser Source
Maximum Laser Power: 6000 Watts
IPG Chiller
Remote Access
Laser Cutting Head
Autofocus
Focus Length: 150 mm
Remote Access
Other Information
Motion: Rack and Pinion
Shuttle Table: Automatic
Lateral Scrap Conveyors: Automatic
Safety: Light Curtains
Dust and Fume Extraction System: Capacity 2500 scfm; Model PL-4000
Bevel: 5-Axis Bevel Head for Full Contour Beveling
Equipped With
Dust Collector
Chiller
